12
Electric
CIRCUIT
Electric
Steam Table
STATEMENT
H All units come standard with a properly rated cord and plug.
 Poweriscontrolledrstbyadoublepolelightedswitch.
The switch, when closed, enables power to the thermostats.
These capillary bulb thermostats register changes to the temperature and communicates
it to the heating element.
H When the thermostats close, power is then sent to the high limit switch. The high limit
switch is normally closed. It will open if the temperatures exceeds 175°F+-9°F for safety.
H Power passing through the high limit switch will then energize the element. The neutral wire (or
 secondaryloadwirein208Vor240Vsystems)fromtheswitchisdirectedtotheheatingelement.
