Technische Daten
Allgemeine Daten
Nennwärmebelastung und Anschlusswerte
Gasanschluss Propan:
Schneidringverschraubung Ø15L (bei ‚München 8‘ Ø18L
Gasanschluss Erdgas:
Aussengewinde ½ Zoll
Elektroanschluss:
1 Phasen, 230 V, 50 Hz
Elektroversion:
3 Phasen, 400/230 V, 50 Hz
Modell
München 3 Kompakt
München 4 Kompakt
München 5 Kompakt
Maße B/T/H (mm):
1080/573/1010
1080/573/1180
1080/573/1350
Gewicht ca. (kg):
105
119
133
Anzahl Spieße:
5
7
9
Modell München 6 ES München 7 ES München 4 Standard
Maße B/T/H (mm): 1283/573/1520 1283/573/1690 1283/573/1180
Gewicht ca. (kg): 174 192 140
Anzahl Spieße: 11 13 9
Modell
München 6 Standard
München 7 Standard
München 8 Standard
Maße B/T/H (mm):
1283/573/1520
1283/573/1690
1283/573/2090
Gewicht ca. (kg):
174
192
222
Anzahl Spieße:
11
13
15
Nennwärmebelastung
Erdgas
in Kilowatt (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
H und E (G20) (20 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
E+ (G20) (20 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
LL (G25) (20 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
L (G25) (25 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
Flüssiggas
in Kilowatt (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
B/P (G30) (29 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
B/P (G30) (50 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
Elektro
in Kilowatt (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
Elektrische Leistung
10,2
13,6
17,0
16,0
24,0
28,0
32,0
Anschlusswert
Erdgas
in Kubikmeter je Stunde (m³/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
H und E (G20) (20 mbar)
1,05
1,40
1,75
2,12
3,18
3,71
4,20
E+ (G20) (20 mbar)
1,05
1,40
1,75
2,12
3,18
3,71
4,20
LL (G25) (20 mbar)
1,23
1,64
2,05
1,96
2,94
3,43
3,92
L (G25) (25 mbar)
1,23
1,64
2,05
1,96
2,94
3,43
3,92
Flüssiggas
in Kilogramm je Stunde (kg/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
B/P (G30) (29 mbar)
0,60
0,80
1,00
1,28
1,92
2,24
2,56
B/P (G30) (50 mbar)
0,78
1,04
1,30
1,56
2,34
2,73
3,12
Elektro
in Kilowatt/Stunde (kW/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
Elektrische Leistung
10,3
13,7
17,1
16,1
24,1
28,1
32,1
Technical Data
General Data
Nominal Heat Input and Connection Values
Gas port propane:
Compression type fitting, diameter 15L (diameter 18L for 'München 8')
Gas port natural gas:
Outside thread ½ inch
Electric power socket :
1 phase, 230 V, 50 Hz
Electricity version:
3 phase, 400/230 V, 50 Hz
Model
Munich 3 Compact
Munich 4 Compact
Munich 5 Compact
Dimensions W/D/H (mm):
1080/573/1010
1080/573/1180
1080/573/1350
Approx. weight (kg):
105
119
133
Number of spits:
5
7
9
Model Munich 6 ES Munich 7 ES Munich 4 Standard
Dimensions W/D/H (mm): 1283/573/1520 1283/573/1690 1283/573/1180
Approx. weight (kg): 174 192 140
Number of spits: 11 13 9
Modell
Munich 6 Standard
Munich 7 Standard
Munich 8 Standard
Dimensions W/D/H (mm):
1283/573/1520
1283/573/1690
1283/573/2090
Approx. weight (kg):
174
192
222
Number of spits:
11
13
15
Nominal Heat Input
Naturala gas
in kilowatts (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
H and E (G20) (20 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
E+ (G20) (20 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
LL (G25) (20 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
L (G25) (25 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
Liquified gas
in kilowatts (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
B/P (G30) (29 mbar)
7,5
10,0
12,5
16,0
24,0
28,0
32,0
B/P (G30) (50 mbar)
9,9
13,2
16,5
20,0
30,0
35,0
40,0
Electric
in kilowatts (kW)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
Electric output
10,2
13,6
17,0
16,0
24,0
28,0
32,0
Nominal Heat Input
Naturala gas
in cubic meters per hour (m³/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
H and E (G20) (20 mbar)
1,05
1,40
1,75
2,12
3,18
3,71
4,20
E+ (G20) (20 mbar)
1,05
1,40
1,75
2,12
3,18
3,71
4,20
LL (G25) (20 mbar)
1,23
1,64
2,05
1,96
2,94
3,43
3,92
L (G25) (25 mbar)
1,23
1,64
2,05
1,96
2,94
3,43
3,92
Liquified gas
in kilograms per hour (kg/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
B/P (G30) (29 mbar)
0,60
0,80
1,00
1,28
1,92
2,24
2,56
B/P (G30) (50 mbar)
0,78
1,04
1,30
1,56
2,34
2,73
3,12
Electric
in kilowatts per hour (kW/h)
M3K
M4K
M5K
M4St./ES
M6St./ES
M7St./ES
M8St./ES
Electric output
10,3
13,7
17,1
16,1
24,1
28,1
32,1
