KTM 1090 Adventure R User Manual

TABLE OF CONTENTS
8
16.17 ACC1 and ACC2 rear ...................... 240
17 COOLING SYSTEM .................................... 241
17.1 Checking the coolant level in the
compensating tank......................... 241
17.2 Correcting the coolant level in the
compensating tank......................... 243
18 TUNING THE ENGINE............................... 245
18.1 "Drive Mod" ................................... 245
18.2 Traction control (TC) ...................... 246
19 SERVICE WORK ON THE ENGINE .............. 247
19.1 Checking the engine oil level........... 247
19.2 Changing the engine oil and oil
filter, cleaning the oil screens ...... 248
19.3 Adding engine oil........................... 255
20 CLEANING, CARE ..................................... 258
20.1 Cleaning motorcycle ....................... 258
20.2 Checks and maintenance steps for
winter operation............................. 261
21 STORAGE................................................. 263
21.1 Storage ......................................... 263
21.2 Preparing for use after storage......... 264
22 TROUBLESHOOTING ................................ 265
23 TECHNICAL DATA..................................... 268
23.1 Engine.......................................... 268
23.2 Engine tightening torques ............... 270
23.3 Capacities ..................................... 275
23.3.1 Engine oil ................................. 275
23.3.2 Coolant..................................... 275
23.3.3 Fuel ......................................... 275
23.4 Chassis ......................................... 276
23.5 Electrical system............................ 277
23.6 Tires............................................. 278
23.7 Fork.............................................. 279
23.8 Shock absorber.............................. 280
23.9 Chassis tightening torques .............. 282
24 SUBSTANCES .......................................... 287
25 AUXILIARY SUBSTANCES ......................... 291
26 STANDARDS ............................................ 293
27 INDEX OF SPECIAL TERMS ....................... 294
28 LIST OF ABBREVIATIONS.......................... 295
29 LIST OF SYMBOLS.................................... 296
29.1 Red symbols.................................. 296

KTM 1090 Adventure R Specifications

General

Displacement	1050 cc
Torque	109 Nm
Transmission	6-speed
Fuel Capacity	23 liters
Seat Height	890 mm
Dry Weight	207 kg
Front Suspension	WP USD Ø 48 mm
Bore x Stroke	103 mm x 63 mm
Compression Ratio	12.5:1
Starter	Electric starter
Fuel System	Electronic fuel injection
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Ground Clearance	250 mm
Engine Type	V-Twin, 4-stroke, DOHC
Power	125 hp (92 kW)
Rear Suspension	WP shock absorber
Front Brake	2 x 320 mm discs, 4-piston radial fixed calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9M+ two-channel ABS (disengageable)
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
