KTM 1090 Adventure R User Manual

TABLE OF CONTENTS
7
13.27 Removing the wind shield ............... 164
13.28 Installing the wind shield................ 164
13.29 Removing the engine guard............. 165
13.30 Installing the engine guard ............. 165
13.31 Removing the crash bar .............. 166
13.32 Installing the crash bar ............... 168
14 BRAKE SYSTEM ....................................... 172
14.1 Antilock brake system (ABS) ........... 172
14.2 Checking the brake discs ................ 175
14.3 Checking the front brake fluid
level ............................................. 176
14.4 Adding front brake fluid .............. 177
14.5 Checking the front brake linings ...... 180
14.6 Checking the rear brake fluid
level ............................................. 181
14.7 Adding rear brake fluid ............... 182
14.8 Checking the rear brake linings ....... 185
15 WHEELS, TIRES ....................................... 186
15.1 Removing the front wheel ............ 186
15.2 Installing the front wheel ............ 188
15.3 Removing the rear wheel ............. 192
15.4 Installing the rear wheel .............. 195
15.5 Checking the rear hub rubber
dampers .................................... 198
15.6 Checking the tire condition ............. 200
15.7 Checking the tire air pressure.......... 202
15.8 Checking spoke tension .................. 203
15.9 Tubeless tire system....................... 205
16 ELECTRICAL SYSTEM ............................... 206
16.1 Daytime running light..................... 206
16.2 Removing the battery .................. 207
16.3 Installing the battery ................... 209
16.4 Recharging the battery ................ 212
16.5 Changing the main fuse.................. 217
16.6 Changing the fuses in the fuse
box............................................... 220
16.7 Removing the headlight mask with
the headlight ................................. 223
16.8 Installing the headlight mask with
the headlight ................................. 224
16.9 Changing the low beam bulb ........... 226
16.10 Changing the high beam bulb.......... 228
16.11 Changing the turn signal bulb ......... 230
16.12 Checking the headlight setting ........ 231
16.13 Adjusting the headlight range.......... 232
16.14 Activating/deactivating the ignition
key ............................................... 233
16.15 Diagnostics connector .................... 239
16.16 Front ACC1 and ACC2 .................... 240

KTM 1090 Adventure R Specifications

General

Displacement	1050 cc
Torque	109 Nm
Transmission	6-speed
Fuel Capacity	23 liters
Seat Height	890 mm
Dry Weight	207 kg
Front Suspension	WP USD Ø 48 mm
Bore x Stroke	103 mm x 63 mm
Compression Ratio	12.5:1
Starter	Electric starter
Fuel System	Electronic fuel injection
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Ground Clearance	250 mm
Engine Type	V-Twin, 4-stroke, DOHC
Power	125 hp (92 kW)
Rear Suspension	WP shock absorber
Front Brake	2 x 320 mm discs, 4-piston radial fixed calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9M+ two-channel ABS (disengageable)
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
