23.2 Engine tightening torques
Screw plug, water pump drain hole EJOTALtracs
®
Plus 60x14 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, bleeder flange EJOTALtracs
®
M6x12 8 Nm (5.9 lbf ft)
Loctite
®
243™
Hose clamp, intake flange M4 2.5 Nm (1.84 lbf ft)
Nozzle, engine vent M5 2 Nm (1.5 lbf ft)
Oil nozzle for piston cooling M5 2 Nm (1.5 lbf ft)
Oil nozzle in cylinder head M5 2 Nm (1.5 lbf ft)
Remaining screws, engine M5 6 Nm (4.4 lbf ft)
Screw, cam lever axial lock M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, gear position sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)
Screw, pressure plate M5 3 Nm (2.2 lbf ft)
Loctite
®
243™
Screw, shift drum retaining bracket M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, shift shaft sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
