6 CONTROLS

38

6.1 Clutch lever

V01187-10

Clutch lever

1

is fitted on the handlebar on the left.

6.2 Hand brake lever

K01350-10

The hand brake lever

1

is located on the right side of the han-

dlebar.

The front brake is engaged using the hand brake lever.
