4 TECHNICAL DATA 11
4.1 Chassis tightening torques
Exhaust clamp - 19 Nm (14 lbf ft) –
Screw, chain guard EJOT PT
®
K60x30 4 Nm (3 lbf ft) –
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft) –
Remaining screws, chassis M4 4 Nm (3 lbf ft) –
Screw, EFI control unit M4 3 Nm (2.2 lbf ft) –
Nut, reflector on retaining plate M5 7 Nm (5.2 lbf ft) –
Nut, retaining plate on license plate
holder
M5 4 Nm (3 lbf ft) –
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –
Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –
Screw, ABS hose clamp (RC 125) M5 6 Nm (4.4 lbf ft) –
Screw, anti-rotation lock, handlebar
stub
M5 4 Nm (3 lbf ft) –
Screw, battery compartment M5 4 Nm (3 lbf ft) –
Screw, chain guard M5 7 Nm (5.2 lbf ft) Loctite
®
204™
Screw, cover in front of battery com-
partment
M5 4 Nm (3 lbf ft) –
Screw, fuel pump M5 5 Nm (3.7 lbf ft) –
Screw, fuel tank cover M5 5 Nm (3.7 lbf ft) –
Screw, rollover sensor M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, side stand switch M5 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, tail end lower part M5 4 Nm (3 lbf ft) –
Cap bolt, footrest M6 9 Nm (6.6 lbf ft) –
Nut, foot brake lever adjustment M6 9 Nm (6.6 lbf ft) –
Nut, license plate bracket M6 8.5 Nm (6.27 lbf ft) –
Nut, shift rod M6 10 Nm (7.4 lbf ft) –
Nut, shift rod M6LH 10 Nm (7.4 lbf ft) –
Nut, tail light M6 7 Nm (5.2 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ABS module on ABS module
retaining bracket (RC 125)
M6 7 Nm (5.2 lbf ft) –
Screw, ABS module retaining bracket
on silent block (RC 125)
M6 7 Nm (5.2 lbf ft) –
Screw, air filter box lid M6 3 Nm (2.2 lbf ft) –
Screw, air filter box, on frame M6 6 Nm (4.4 lbf ft) –
Screw, battery compartment M6 6 Nm (4.4 lbf ft) –
Screw, brake fluid container, front
brake
M6 8 Nm (5.9 lbf ft) –
Screw, brake fluid container, rear
brake
M6 7 Nm (5.2 lbf ft) –
Screw, brake line guide on bottom
triple clamp
M6 7 Nm (5.2 lbf ft) Loctite
®
243™
Screw, cable holder, side stand switch M6 9 Nm (6.6 lbf ft) Loctite
®
243™
Screw, chain guard M6 7 Nm (5.2 lbf ft) –
Screw, chain sliding guard M6 7 Nm (5.2 lbf ft) –
Screw, compensating tank M6 9 Nm (6.6 lbf ft) –
Screw, engine sprocket cover on frame M6 7 Nm (5.2 lbf ft) –
Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft) Loctite
®
243™
Screw, footrest bracket M6 7 Nm (5.2 lbf ft) –
Screw, front fender on axle clamp M6 7 Nm (5.2 lbf ft) –
Screw, front fender, top side M6 7 Nm (5.2 lbf ft) –
Screw, front mask M6 7 Nm (5.2 lbf ft) –
