2
Connect your charger to an electrical outlet (AC).
3
Turn on the power switch on the charger.
4
Wait for 30 seconds.
5
Connect the charger cable to the battery connector on your bike.
CAUTION!
If the charger is plugged into the bike with the charger switched OFF, a potential in-rush of electri-
cal current from the bike’s battery to the charger may damage the charger.
The recommended charging time for a fully discharged battery is 2.5 hours
After 1.5 hours of charging, the battery should be charged to about 80 %
After 2.5 hours, the battery should be charged to 99 % of capacity
WARNING!
Only use the supplied battery charger. Using any other battery charger will void the warranty and
may damage the battery.
The LED light on the charger will illuminate RED while charging.
The LED light on the charger will illuminate GREEN when the battery is fully charged.
