Specifications - 194 RT120Q Operator’s Manual
RT120Q Tractor
Operation U.S. Metric
Forward speeds
Low 2.0 mph 3.2 km/h
Medium 4.4 mph 7.1 km/h
High 7.2 mph 11.6 km/h
Reverse speeds
Low 2.0 mph 3.2 km/h
Medium 4.4 mph 7.1 km/h
High 4.7 mph 7.5 km/h
Vehicle clearance circle (SAE) wall to wall with optional backfill blade
Front steer only 39.5 ft 12 m
Coordinated steer 27 ft 8.2 m
Ground clearance 15.5 in 394 mm
Basic unit weight 13,600 lb 6169 kg
Maximum allowable tractor weight 26,200 lb 11,884 kg
Front counterweight 1300 lb 590 kg
Side counterweight (each) 250 lb 114 kg
Backfill Blade (optional) U.S. Metric
Blade width 80 in 2.03 m
Blade height 17 in 430 mm
Lift height above ground 26 in 660 mm
Blade drop below ground 10 in 254 mm
Maximum swing angle (left/right) 30° 30°
Tilt angle (up/down) 24° 24°
