Kunde Andros - Parts Identification

34
EN
List of parts:
Parts
No.:
Article
No.:
Illustration / descrip
tion:
Quantity:
A
---
Umbrella, pre-assembled
1
B
9114-618-00
(Set)
Screws & washers, M8 x 20
4
C
Screw & nut, M6 x 50
1
D
9111-618-00
Cross base, top part
1
E
9112-618-00
Cross base, bottom part
1
F
9113-618-00
Tube
1
G
---
Allen key
1
H
---
Open end wrench
1
To order replacement parts please contact the retailer where you
purchased the umbrella.
Use the article numbers listed above to make sure you order the
right part.
