K2600 ADAT I/O Option User’s Guide / OS 4.1 Release Notes
New Objects included with the ADAT Option
New Objects included with the ADAT Option
K26ADAT.K26 (included on disk with the ADAT option) provides two programs and a KDFX studio for use with
the ADAT option. These objects are described below. Use Disk Mode to load the K26ADAT.K26 file.
Remember that in order to use the ADAT inputs, the source must be synchronized to the K2600. In other words,
the K2600 must provide the master clock signal. This is accomplished by connecting the K2600's ADAT output to
the source's ADAT input.
Program 200: ADAT in 8 mono
processes the 8 channels from your ADAT input individually. Press and hold a key,
and use the 8 sliders (A through H) to mix the 8 channels. Use the ModWheel to add Aux reverb to all 8 channels.
Use SW2 to enable Insert FX. If you get tired of holding the key down, you can edit the program's 8 layers and turn
on
IgnRel
on the Layer page.
Program 201: ADAT in 4 stereo
processes the 8 channels from your ADAT input as 4 stereo pairs. Press and hold a
key, then use the 4 sliders (A through D) to mix the 4 stereo signals. Use the other 4 sliders (E through H) to adjust
the Insert FX wet/dry balance. Use the ModWheel to add Aux reverb to all 8 channels. Use SW2 to change Aux
reverb time.
The table below summarizes controller assignments in these two programs.
KDFX Studio 200: 6 Mono FX Hall
supports mono FX for program 200. Outputs are set as follows:
Output A: Mix
Output B: Off
Output C: Off
Output D: Off
These KDFX output settings present a Mix of the 8 ADAT channels at the Analog Mix outs, Analog A outs, and
ADAT 1+2. If you wish to have 8 discrete ADAT output channels, use the following KDFX Output settings :
Output A: PostFX1
Output B: PostFX2
Output C: PostFX3
Output D: PostFX4
Program 200: ADAT in 8 mono Program 201: ADAT in 4 stereo
MWheel Aux Reverb send for all channels MWheel Aux Reverb send for all channels
Data Volume for ADAT in 1 Data Volume for ADAT in 1+2
MIDI 22 Volume for ADAT in 2 MIDI 22 Volume for ADAT in 3+4
MIDI 23 Volume for ADAT in 3 MIDI 23 Volume for ADAT in 5+6
MIDI 24 Volume for ADAT in 4 MIDI 24 Volume for ADAT in 7+8
MIDI 25 Volume for ADAT in 5 MIDI 25 Insert FX Wet/Dry for ADAT in 1+2
MIDI 26 Volume for ADAT in 6 MIDI 26 Insert FX Wet/Dry for ADAT in 3+4
MIDI 27 Volume for ADAT in 7 MIDI 27 Insert FX Wet/Dry for ADAT in 5+6
MIDI 28 Volume for ADAT in 8 MIDI 28 Insert FX Wet/Dry for ADAT in 7+8
MIDI 29 (Sw2) Enables Insert FX for all channels MIDI 29 (Sw2) Aux Reverb Time
