KUSSMAUL AUTO-PUMP - Auto-Pump Specifications and Outline Drawings

170 Cherry Avenue
West Sayville, NY 11796
www.kussmaul.com
Ph: 800-346-0857
Fax: 631-567-5826
sales@kussmaul.com
6
Input : 120 volts A.C., 50/60 Hz, 1.8 amps
Weight: 15 lbs
Motor Horsepower: 1/8 HP
Motor Type: Shaded pole A.C.
Compressor Output: 1.0/1.3 CFM Open Flow, 100 PSI Maximum.
Pressure Switch: Adjustable Set Point-Factory
set to 75 PSI Cut-in, 95 PSI Cut-out
Switch Differential: 20 PSI Nominal
Outlet Connection: 1/4 NPT, Female
185.77
7.31
3X
88.90
3.50
2X
121.92
4.80
2X, 1.75
38.10
1.50
7.08
179.84
2X,
150.99
5.94
6X, 1/4-20
TAPPED HOLES
195.91
7.71
SPECIFICATION & OUTLINE AUTO PUMP
