KVH Industries 1775 IMU User Manual

56-0298 Rev B
This document contains proprietary information of KVH Industries, Inc. and neither this document nor said proprietary information shall be
published, reproduced, copied, disclosed, or used for any purpose without the express written permission of a duly authorized KVH representative.
Page 15 of 77
Table 5-3: Normal Operating Mode Message Format B
Item
Byte Numbers
Description
Header
1-4
Always 0xFE81FF56 (transmitted 0xFE first)
Message Data
5-36
(refer to Table 5-4)
CRC (Cyclic
Redundancy Check)
37-40
(refer to Table 5-9)
TOTAL
40
Table 5-4: Normal Operating Mode Data Format B
Datum
Byte Numbers
Data
Type*
Units
Notes
X rotational data
5, 6, 7, 8
SPFP
Radians or
degrees,
selectable
MSB (Byte 4) is output first;
delta angle or rate of
rotation, selectable
Y rotational data
9, 10, 11, 12
SPFP
Radians or
degrees,
selectable
MSB (Byte 8) is output first;
delta angle or rate of
rotation, selectable
Z rotational data
13, 14, 15, 16
SPFP
Radians or
degrees,
selectable
MSB (Byte 12) is output
first; delta angle or rate of
rotation, selectable
X Acceleration
17, 18, 19, 20
SPFP
g
MSB (Byte 16) is output first
Y Acceleration
21, 22, 23, 24
SPFP
g
MSB (Byte 20) is output first
Z Acceleration
25, 26, 27, 28
SPFP
g
MSB (Byte 24) is output first
Timestamp
29, 30, 31, 32
UINT32
Microseconds
MSB (Byte 28) is output first
Status
33
DISC
1 = valid data
0 = invalid data
(refer to Table 5-8)
Sequence number
34
UINT8
0-127
Increments for each
message and resets to 0
after 127
Temperature
35,36
INT16
°C, 1/100 °C,
°F, 1/100 °F,
selectable
* SPFP = Single Precision Floating Point (IEEE-754 Big-endian format); DISC = Discrete Data; UINT8 =
Unsigned 8-bit integer; INT16 = Signed 16-bit integer
