Kyocera ECOSYS PA2100cx User Manual

8-17
Troubleshooting > Troubleshooting
P
R
Message Checkpoints Corrective Actions
Reference
Page
Paper jam
#####################
― If a paper jam occurs, the machine
will stop and the location of the jam
will be indicated on the screen.
Leave the machine on and select
[Help]. Follow the instruction to
remove the jammed paper.
page 8-25
Paper path error ― There is no paper cassette in the
printer, or the cassette is not
inserted properly. After reinserting
the paper cassette, you should be
able to print. When two or more
optional feeders are installed and
the lowest one is selected, the
same message will appear if any of
the upper paper feeder and the
printer cassette is improperly
installed.
―
Please wait (Calibrating) ― The machine is under the
adjustment to maintain its quality.
Please wait.
―
Please wait
(Cooling)
― The machine is under the
adjustment to maintain its quality.
Please wait.
―
Message Checkpoints Corrective Actions
Reference
Page
RAM disk error
Press GO
― An error has occurred on the RAM
disk. Job is canceled. Select the
[GO] key.
The error code is as follows.
04: Insufficient space on the RAM
disk. If the optional RAM disk is
installed, increase the RAM disk
size by changing RAM Disk Size in
Menu.
page 6-18
Replace the toner.
[C][M][Y][K]
― Replace the toner container to our
specified toner container. Select the
[GO] key to print using the
remaining black toner for a while.
page 8-3

Kyocera ECOSYS PA2100cx Specifications

General

Color	Yes
N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Booklet printing function	No
Time to first page (black, normal)	11 s
Time to first page (color, normal)	12.5 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	21 ppm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	33 W
Power consumption (printing)	345 W
Power consumption (PowerSave)	0.9 W
Energy Star Typical Electricity Consumption (TEC)	0.691 kWh/week
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	65000 pages per month
Recommended duty cycle	500 - 1500 pages per month
Replacement cartridges	TK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges	4
Page description languages	PDF, PCL 6, XPS, PostScript 3
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
USB connector	USB Type-A
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor family	ARM Cortex
Sound power level (standby)	30 dB
Sound pressure level (printing)	48 dB
Display	LCD
Control type	Buttons
Certification	GS, TUV
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Sustainability certificates	CE
Package depth	567 mm
Package width	592 mm
Package height	460 mm
Package weight	27000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Width	410 mm
Height	329 mm
