Kyocera FS-C8500DN Service Manual

2KA
1-3-117
Drum Performing drum refreshing
Description
Rotates the drum approximately 2 minutes with toner lightly on the overall drum using the
high-voltage output control of the engine PWB. The cleaning blade in the drum unit scrapes
toner off the drum surface to clean it.
Purpose
To clean the drum surface when image failure occurs due to the drum. This mode is effective
when dew condensation on the drum occurs.
Procedure
1. In the Service Setting menu, select [Drum].
2. Press the OK key.
3. Press [Yes] (Left Select key).
Carry out drum refresh.
LSU Performing laser scanner cleaning
Description
The LSU cleaning solenoid drive the cleaning blade which in turn wipes clean the LSU dust
shield glass.
Purpose
To perform cleaning when the printed image is bad and stripes are seen in the vertical direc-
tion.
Procedure
1. In the Service Setting menu, select [LSU].
2. Press the OK key.
3. Press [Yes] (Left Select key).
Carry out the LSU cleaning.
MP Tray Cleaning Performing MP tray cleaning
Description
To perform MP tray cleaning.
Purpose
If dirt appears on images when using the MP tray, perform MP tray cleaning.
Procedure
1. In the Service Setting menu, select [MP tray].
2. Press the OK key.
3. Press [Yes] (Left Select key).
MP tray cleaning starts.
Silent Mode Setting silent mode
Description
Make the machine run more quietly.
Purpose
Select this mode when the running noise is uncomfortable.
Procedure
1. In the Service Setting menu, select [Silent Mode].
2. Press the OK key.
3. Select [On] or [Off].
4. Press the OK key.
Service items Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
