Kyocera KM-1635 - Paper Feeder; Duplex Unit; Key Counter

2HA/2HB
1-4-12
(19)
A paper jam in the
duplex section is indi-
cated during copying
(misfeed in duplex
exit section).
Jam code 61
Broken duplex paper con-
veying switch actuator.
Check visually and replace the duplex paper conveying switch if
its actuator is broken.
Defective duplex paper con-
veying switch.
Run maintenance item U031 and turn duplex paper conveying
switch on and off manually. Replace duplex paper conveying
switch if indication of switch is not light.
Broken registration switch
actuator.
Check visually and replace the registration switch if its actuator is
broken.
Defective registration
switch.
Run maintenance item U031 and turn registration switch on and
off manually. Replace registration switch if indication of switch is
not light.
Check if the duplex feed
clutch malfunctions.
Check visually and remedy if necessary.
Electrical problem with the
duplex feed clutch.
Check.
Problem
Causes/check procedures Corrective measures
