2HA/2HB
2-3-3
YC5 1 +5 V1 O 5 V DC power supply for FCSSW
Connected
to the front
cover safety
switch
2 NC - Not used
3 +5 V3 I 5 V DC power supply
YC6 1 H.LIVE O AC power supply for FH-M/S (LIVE)
Connected
to the fuser
heater M/S
2 MH.OUT O AC power supply for FH-M
3 MH.OUT O AC power supply for FH-S
YC7 1 DH2.LIVE O AC power supply for drawer heater of the paper feeder (LIVE)
Connected
to the
optional
paper feeder
2 NC - Not used
3 NC - Not used
4 DH2.OUT O AC power supply for drawer heater of the paper feeder
YC8 1 DH1.LIVE O AC power supply for drawer heater (LIVE)
Connected
to the
optional
drawer
heater
2 NC - Not used
3 NC - Not used
4 DH1.OUT O AC power supply for drawer heater
YC9 1 +24 V1 O 24 V DC power supply for paper feeder
Connected
to the
optional
paper feeder
2 PGND - Ground
Connector Pin No. Signal I/O Description
