2JL/2JJ/2JG/2JD
1-5-5
4. Remove one connector.
5. Remove the MP tray.
Figure 1-5-9
6. Remove two screws and one connector, and
remove the MP unit.
Figure 1-5-10
MP tray
Connector
MP unit
Connector
