2JL/2JJ/2JG/2JD
1-2-13
5. Remove the inserted parts and then remove
the interface cover.
Figure 1-2-17
6. Open the front cover.
7. Remove five screws and remove the right
cover.
Figure 1-2-18
8. Remove one screw and then remove the
interface rear cover.
Figure 1-2-19
Interface cover
Right cover
Front cover
Screw
Screw
Screw
Screw
Screw
Interface rear cover
Screw
