Kyocera KM-C3232E Service Manual

2JL/2JJ/2JG/2JD
1-2-14
9. Remove the upper right cover.
10. Cut out the aperture plate on the upper right
cover using nippers.
Figure 1-2-20
11. Attach the key counter mount to the rear
upper frame using the M4 x 8 screw.
Figure 1-2-21
Upper right cover
Aperture
Key counter
mount
M4 x 8 screw
(B1A54080)
