2JN
1-3-12
U032
Checking clutch operation
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the start key.
2. Select the clutch to be operated using the cursor up/down keys.
3. Press the start key. The clutch turns on.
*: Option.
4. To stop driving motors, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U033
Checking solenoid operation
Description
Applies current to each solenoid in order to check its ON status.
Purpose
To check the operation of each solenoid.
Method
1. Press the start key.
2. Select the solenoid to be operated using the cursor up/down keys.
3. Press the start key. The solenoid turns on.
*Option.
4. To stop driving motors, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Clutches
FEED CL Paper feed clutch operates
REG CL Registration clutch operates
DLP CL Developing clutch operates
FEED CL(PF1) PF paper feed clutch* operates
TRANS CL(PF1) PF paper conveying clutch* operates
FEED CL(PF2) PF paper feed clutch* operates
TRANS CL(PF2) PF paper conveying clutch* operates
Display Solenoids
MPF SOL MP paper feed solenoid operates
DU SOL Duplex solenoid operates
FD SOL Face down solenoid operation
