2KJ/2KH
1-4-23
C7800 Broken external thermistor wire
The thermistor output value is 0.5 V or
less.
Poor contact in the
connector termi-
nals.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective humidity
sensor.
Replace the cassette PWB and check for
correct operation.
C7810 Short-circuited external thermistor
wire
The thermistor output value is 4.5 V or
more.
Poor contact in the
connector termi-
nals.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective humidity
sensor.
Replace the cassette PWB and check for
correct operation.
C8170 Built-in finisher front side registration
motor problem
When the front-side registration home-
position sensor is turned on during initial-
ization, the sensor did not turn on while it
has moved by 106 pulses.
When the front-side registration home-
position sensor is turned off during initial-
ization, the sensor did not turn on in 3 s.
The front side reg-
istration motor con-
nector makes poor
contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective front side
registration motor.
Replace front side registration motor.
The front side reg-
istration home
position sensor
connector makes
poor contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective front side
registration home
position sensor.
Replace the front side registration home
position sensor.
Defective finisher
control PWB.
Replace the finisher control PWB and check
for correct operation.
C8180 Built-in finisher rear side registration
motor problem
When the rear-side registration home-
position sensor is turned on during initial-
ization, the sensor did not turn on while it
has moved by 106 pulses.
When the rear-side registration home-
position sensor is turned off during initial-
ization, the sensor did not turn on in 3 s.
The rear side reg-
istration motor con-
nector makes poor
contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective rear side
registration motor.
Replace rear side registration motor.
The rear side reg-
istration home
position sensor
connector makes
poor contact.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
remedy or replace the cable.
Defective rear side
registration home
position sensor.
Replace the rear side registration home
position sensor.
Defective finisher
control PWB.
Replace the finisher control PWB and check
for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures
