2MV
1-5-56
4. Rotate the wire cover.
5. Remove two connectors.
6. Rotate the fulcrum axis and slide it for-
ward.
7. Pull the right cover 1 backward and
then remove it.
Figure 1-5-102
Fulcrum axis
Connectors
Right cover 1
Wire cover
