KYT NFJ - Helmet Ventilation System; Front Air Intake Operation; Rear Air Vent Functionality

FRONT AIR INTAKE UPPER — F — Figure 2/3
The ow of incoming air in the upper front part of the helmet may be regulated by sliding the
cursor on the air intake:
- Figure 2: Slide the cursors forwards to completely close the air intake
- Figure 3: Slide the cursors backwards to completely open the air intake
REAR AIR VENTS — G — Figure 4
The innovative rear air intake has been designed to further improve ventilation inside the helmet,
using residual air ows that, thanks to the Venturi eect, are able to generate a depression in
the lower part of the helmet, in order to ensure a substantial extraction of the hot air inside it,
consequently maintaining a comfortable temperature.
FIGURE 2 FIGURE 3
FIGURE 4
