L-Acoustics LA4X User Manual

Operation
Modifying the IP address
‾NETWORK ADDRESS ‼※
192 . 168 . 1 . 100
NETWORK ADDRESS
192 . 168 . 1 .>100<
OK
‾NETWORK ADDRESS ‼※
192 . 168 . 1 . 101
+OK
Procedure
1. From the main menu, select OPTIONS.
2. Press the OK key or the encoder wheel to validate.
3. Turn the encoder wheel to select NETWORK ADDRESS.
4. Turn the encoder wheel to select a value for the last byte (the last number).
Turn the encoder wheel for 1-step resolution.
Press and turn the encoder wheel for 10-step resolution.
5. Press the OK key to validate.
Subnet modication
According to the network administration requirements the default subnet (192.168.1.0) can be modied.
Use only Subnet prexes corresponding to private local area networks according to RFC1918 for LA Network
Manager to be able to connect to the amplied controllers.
Subnet mask is automatically dened in rmware according to the network class induced by the Subnet prex
(class A, class B, class C).
6. If needed, set another byte (rst, second or third number) as follows:
a) Long-press the OUT key under the byte to select it.
b) Turn the encoder wheel to select a value.
c) Press the OK key to validate.
d) In LA Network Manager:
1. Click the L-Acoustics logo and select Options.
2. Enter the corresponding values in IP Range to scan for L-NET.
DELAY UNIT
Delay values can be displayed in ms (milliseconds), meters, feet or samples. The values in meters and feet are given for a
temperature of 20° C / 68° F.
OK
+OK
‽DELAY UNIT ‼※
ms
DELAY UNIT
>ms<
‽DELAY UNIT ‼※
SAMPLES
Procedure
1. From the main menu, select OPTIONS.
2. Press the OK key or the encoder wheel to validate.
3. Turn the encoder wheel to select DELAY UNIT.
4. Press the OK key or the encoder wheel to validate.
5. Turn the encoder wheel to select the value.
LA4X user manual (EN) version 9.1 48
