L-Acoustics LA4X Maintenance Manual

Disassembly and Reassembly procedures
D/R 004 – Power plug
Tools
Name
Reference
Distributor
wire stripping pliers
793936
Facom
Stanley knife
0-10-018
Stanley
screwdriver adapted to the new power
plug
—
—
Spare parts
N
o
Description
Qt
y
1
power plug
1
Safety
There is a risk of electrical injury when the high-voltage capacitors are charged.
Before the maintenance operation, disconnect the POWER CORD from the mains and from the
controller.
Replacement procedure
This procedure describes how to replace the power plug on a POWER CORD.
Unplug the POWER CORD from the mains.
Unplug the POWER CORD from the controller.
Cut the POWER CORD near the power plug.
Use the Stanley knife.
Strip the three wires of the POWER CORD on a length compatible with the new plug.
Use the Stanley knife and the wire stripping pliers.
Fix the three wires on the new plug according to the color code of Table 1.
Use the screwdriver.
Table 1: Wire color code
Controller
Live
Neutral
Ground
AMPCORDONCE
brown
blue
green / yellow
AMPCORDONCN
AMPCORDONUS
black
white
green
