Laars VW - Page 9

Mighty Therm VW - PW Volume Water Heaters
Page 9
REAR TILE COVER
FLOW SWITCH
CONDUIT
GAP CLOSURE
GROMMET
DRAIN
VALVE
METAL CHANNEL
(FOR CAPILLARY TUBE)
TERMINAL STRIP
HEAT EXCHANGER
ASSEMBLY
GAP CLOSURE
DRAIN PLUG
DRAIN VALVE
REAR TILE
COVER
HEX HEAD
SCREWS
MANUAL RESET
HIGH LIMIT
SWITCH BOX
Figure 15. Heat exchanger reversal.
Figure 16. Flue collector Holddown Clamps.
Flue Collector
Clamp
In/Out Header
Bracket
Heat Exchanger
Clamp
Bracket
