Page #13 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NO=ENTF=
=
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position ACNC-2C ACNC-2S ACNC-3C
C10A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C10B - - 100n63VMMK5
C11A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C11B - - 100n63VMMK5
C12A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C12B - - 100n63VMMK5
C13A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C13B - - 100n63VMMK5
C15 680p400VK20005%5 680p400VK20005%5 6n8250VMMK5
C18A - - 68n63VMMK5
C19A - - 68n63VMMK5
C20A - - 68n63VMMK5
C21A - - 68n63VMMK5
C22 - - 100p200VNP05%5
C23 - - 680p400VK20005%5
C24 - - 47u25V
C28 - - 47u25V
C31 - - 47u25V
C32 - - 47p100VNP05%5
C33 - - 470p200VNP05%5
C38 - - 150p500VK20005%5
C210A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C210B - - 100n63VMMK5
C211A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C211B - - 100n63VMMK5
C212A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C212B - - 100n63VMMK5
C213A 220n63VMMK5 330n63VMMK5 330n63VMMK5
C213B - - 100n63VMMK5
C215 680p400VK20005%5 680p400VK20005%5 6n8250VMMK5
C218A - - 68n63VMMK5
C219A - - 68n63VMMK5
C220A - - 68n63VMMK5
C221A - - 68n63VMMK5
C222 - - 100p200VNP05%5
C223 - - 680p400VK20005%5
C224 - - 47u25V
C228 - - 47u25V
C231 - - 47u25V
C232 - - 47p100VNP05%5
C233 - - 470p200VNP05%5
C238 - - 150p500VK20005%5
D8 - - 1N4148
D9 - - 1N4148
D208 - - 1N4148
D209 - - 1N4148
D504 - - 1N4148
K4 - - NC3MA-H_NEU
K204 - - NC3MA-H_NEU

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
