11
DESCRIPTION: (Con’t)
315/317 SERIES FLO-THRU CO2 INCUBATORS:
BASIC COMPONENTS, AN INITIAL OVERVIEW:
1
2 3 4 5 6 7 8 9 10
1. AIR & CO2
FLOWMETERS
2. UNIT FEET
3. CO2 ACCESS PORT
4. CHAMBER SHELVES
5. TEMPERATURE SENSOR
6. CHAMBER GASKET
7. INNER GLASS DOOR, HANDLE SHAFT
8. INNER GLASS DOOR
9. INNER GLASS DOOR, HANDLE
10. OUTER STEEL DOOR/GASKET
