DESCRIPTION
314/316 SERIES AUTOMATIC CO2 INCUBATORS:
BASIC COMPONENTS, AN INITIAL OVERVIEW:
1 13
14
2
3
4
5
6
7
8
15 9 10 11 12
1. Control panel
2. CO
2
sensor
3. CO
2
inlet port
4. Temperature sensor
5. Chamber gasket
6. Chamber shelves
7. Sample port inlet
8. Leveling feet
9. Inner glass door, handle shaft
10. Inner glass door
11. Inner glass door, handle
12. Outer door gasket
13. CO
2
sample port
14. Fan Cover
15. Humidity Trough
