Chapter 7: Accessorizing and Modifying your Filtered Enclosure
Order the following:
Part Description
3924400 2' Exhaust Transition Kit
3924401 3' Exhaust Transition Kit
3924402 4' Exhaust Transition Kit
4. Remote Blowers
Has a 1/4 hp direct drive motor and corrosion-resistant epoxy-
coated steel housing and wheel with blower inlet of 6.00" ID.
Outlet dimensions are 4.25" x 7.38" OD.
CFM @ Static Pressure-Inches of H
2
O
S.P. 0.0" 0.125" 0.25" 0.50" 0.75" 0.87"
CFM 595 560 515 420 300 167
Catalog
#
Description
Shipping Wt.
(lbs./kg.)
4863500 Remote Blower, 115 V, 60 Hz. 4.4 amps 35/16
4863501 Remote Blower, 115/230 V, 50 Hz, 5.6/2.8 amps 35/16
7053501
Explosion-Proof Remote Blower, 115 V, 60 Hz,
4.4 amps
40/18
Figure 7-1
