LabJack U12 - 5.3 - Counter

'D15toD8Directions':
<BitField object: [ D15 = Input (1), D14 = Input (1),
D13 = Input (1), D12 = Input (1),
D11 = Input (1), D10 = Input (1),
D9 = Input (1), D8 = Input (1) ] >,
'D7toD0OutputLatchStates':
<BitField object: [ D7 = 0 (0), D6 = 0 (0),
D5 = 0 (0), D4 = 0 (0),
D3 = 0 (0), D2 = 0 (0),
D1 = 0 (0), D0 = 0 (0) ] >,
'D15toD8OutputLatchStates':
<BitField object: [ D15 = 0 (0), D14 = 0 (0),
D13 = 0 (0), D12 = 0 (0),
D11 = 0 (0), D10 = 0 (0),
D9 = 0 (0), D8 = 0 (0) ] >,
'D15toD8States':
<BitField object: [ D15 = Low (0), D14 = Low (0),
D13 = Low (0), D12 = Low (0),
D11 = Low (0), D10 = Low (0),
D9 = Low (0), D8 = Low (0) ] >,
'D7toD0Directions':
<BitField object: [ D7 = Input (1), D6 = Input (1),
D5 = Input (1), D4 = Input (1),
D3 = Input (1), D2 = Input (1),
D1 = Input (1), D0 = Input (1) ] >
}
5.3 - Counter
This command controls and reads the 32-bit counter.
Command
Byte #
Description
0
Bits 7-2: XXXXXX
Bit 1: Strobe Enabled
Bit 0: Reset Counter
1
XXXXXXXX
2
XXXXXXXX
3
XXXXXXXX
4
XXXXXXXX
5
01X1XX10 (Counter)
6
XXXXXXXX
7
XXXXXXXX
Response
Byte #
Description
0
01X1XX10 (Counter)
1
Bits for D15 though D8 State ( 0 = Low, 1 = High )
2
Bits for D7 though D0 State ( 0 = Low, 1 = High )
3
Bits 7-4 = IO3 through IO0 State
Bits 3-0 = XXXX
4
Most Significant Byte of Counter
5
Bits 23-16 of Counter
6
Bits 15-8 of Counter
7
Least Significant Byte of Counter
[textile]
This command controls and reads the 32-bit counter.
