LabJack U12 - 5.15 - SHT1 X

Command
Byte #
Description
0
Data Byte 3
1
Data Byte 2
2
Data Byte 1
3
Data Byte 0
4
Bit 7: Wait for measurement ready signal
Bit 6: Issue serial reset
Bit 5: 1ms Delay
Bit 4: 300µs Delay
Bit 3: IO3 State
Bit 2: IO2 State
Bit 1: IO3 Tris (Direction?)
Bit 0: IO2 Tris (Direction?)
5
011X1000 (SHT1X)
6
Number of bytes to write (0-4)
7
Number of bytes to read (0-4)
Response
Byte #
Description
0
Data Byte 3
1
Data Byte 2
2
Data Byte 1
3
Data Byte 0
4
Bit 2: Serial reset error
Bit 1: Measurement ready error
Bit 0: Ack error
5
011X1000 (Echo of byte 5)
6
Echo of byte 6 from Command
7
Echo of byte 7 from Command
LabJackPython Example
>>> import u12
>>> d = u12.U12()
open called
Writing: [0x0, 0x0, 0x0, 0x0, 0x0, 0x57, 0x0, 0x0]
Received: [0x57, 0x0, 0x0, 0x0, 0xff, 0xff, 0x0, 0x0]
>>> results = d.rawSHT1X()
Writing: [0x0, 0x0, 0x0, 0x3, 0x8f, 0x68, 0x1, 0x3]
Received: [0x0, 0x66, 0x34, 0x19, 0x0, 0x68, 0x1, 0x3]
>>> print results
{
'DataByte3': 0, 'DataByte2': 102, 'DataByte1': 52, 'DataByte0': 25,
'ErrorFlags':
<BitField object: [ Serial Reset Error Flag = 0 (0),
Measurement Ready Error Flag = 0 (0),
Ack Error Flag = 0 (0) ] >}
>>> tempC = (results['DataByte0'] * 256 ) + results['DataByte1']
>>> tempC = (tempC * 0.01) - 40
>>> print tempC
24.52
>>> results = d.rawSHT1X(Data = [5,0,0,0])
Writing: [0x0, 0x0, 0x0, 0x5, 0x8f, 0x68, 0x1, 0x3]
Received: [0x0, 0xaa, 0xae, 0x2, 0x0, 0x68, 0x1, 0x3]
>>> print results
{
'DataByte3': 0, 'DataByte2': 170, 'DataByte1': 174, 'DataByte0': 2,
'ErrorFlags':
<BitField object: [ Serial Reset Error Flag = 0 (0),
Measurement Ready Error Flag = 0 (0),
Ack Error Flag = 0 (0) ] >}
>>> sorh = (results['DataByte0'] * 256 ) + results['DataByte1']
>>> rhlinear = (-0.0000028*sorh*sorh)+(0.0405*sorh)-4.0
>>> rh = ((tempC-25.0)*(0.01+(0.00008*sorh)))+rhlinear
>>> print rh
22.4341888
