SHELF SUPPORT LOCATION ILLUSTRATION
ILB-1621
ALL MT'S
REAR
FRONT
1/2" TAB
1/4" TAB
1/2" TAB
1/4" TAB
SHELF SUPPORT - REAR
WITH 1/2" TAB
( FULL SCALE )
SHELF SUPPORT - FRONT
WITH 1/4" TAB
( FULL SCALE )
-- NOTES & INSTRUCTIONS --
1. PLACE SHELF SUPPORTS WITH 1/4" TABS INTO PILASTER AT DESIRED POSITION.
( NOTE THAT SUPPORTS WITH 1/4" TABS ARE LOCATED AT FRONT ONLY )
2. PLACE SHELF SUPPORTS WITH 1/2" TABS INTO PILASTER AT DESIRED POSITION.
( NOTE THAT SUPPORTS WITH 1/2" TABS ARE LOCATED AT BACK ONLY )
