AT2-5
77x35x77 mm
univerSal DeFroSt controller For high anD
low temperature
Selectable Refrigerating or Heating control Runs on mains power supply Direct
compressor control through high power 16(5)A Excellent evaporator fan control
Auxiliary output congurable in six different operating modes Selectable NTC10K or PTC
input Electrical, off cycle or hot gas defrost Absolute or relative temperature alarms
Door open alarm Automatic condenser maintenance warning On/Off button
Optional light control button Quick programming through ZOT-AT2 key
High or Low Temperature upright cabinets and counters, cold stores, plug-in display cases, control
panels, heated cabinets.
applicationS:
BS4E-G BS4E-AG BS4E-AL
thermostat
evaporator
Functions
Inputs
door switch
Outputs
Power supply
thermostat
230Vac
serial port TTL
auxiliary
evaporator fans
Serial port
generic
Keypad
with light button
Models with removable screw terminal blocks are available. In this case, the letter “S” of code changes in “Q”, ex.
AT2-5BQ4E-AL.
All models come with an alarm buzzer. Versions with 110V power supply are available.
Upon request, against large batches, the AT2-5 is also available with RS485 serial port
On request, the AT2-5 is also available with gasket for a better protection between bezel and metal panel.
Control Range: -50÷120°C , -55÷240°F
Resolution: 0.1 / 1 °C; °F
Accuracy: NTC10K: <±0.3°C (-40.0÷70.0°C)
PTC1000: <±0.5°C (-50÷120°C)
Sensor type: selectable NTC10K or PTC1000
Power supply: 230V~ ±10% 50÷60Hz 3W
Front protection: IP55
Panel cut-out: 71x29 mm
technical Data
