Page #48 background imageLoading...
Page #48 background image
14 15 16 17 18 19 9 10 11 7 8 6 1 2
26
29313233 2830 27
DI2
Maximum total current 17.5A
Power
Supply
L
N
data I/O
RS485
PC comm.
LCD-5S
16(4)A
16(8)A
A
B
8(2)A 7A
Evaporator fan
Condenser fan
T3
T2
T1
remote
Door
7A
AUX 2AUX 1
Aux
FUSE
AD2-28C1S5E-B
