Lagoon Seventy 7 - Page 59

Technical handbook
l 57 l
ELECTRICAL MAIN SYSTEM
AC GENERATOR 2 MAIN ELECTRICAL PANEL (AC/DC)CHARGERS
MAIN AC GENERATOR 1 AC INVERTERS
BOW THRUSTER
BATTERIES
MAIN BATTERIES
GALLEY AC BOX
BOW THRUSTER
CHARGER
