I2C device (RTC chip U16) via headers in series (no jumper by default)
SPI device (EEPROM)
QSPI device (Flash IC) via open solderbridges (by default)
Four buttons and four LEDs for user interaction
One reset button (via an analog switch)
NFC antenna connector on-board development board for use with supplied flexi-PCB NFC antenna
Optional external 32.768 kHz crystal oscillator and associated load capacitors. Not required for operation of the BL654;
is disconnected by open solder bridges by default.
Optional external serial (QSPI) flash IC. Not required for operation of the BL654; is disconnected by open solder
bridges by default.
Access to BL654 JTAG also known as Serial Wire Debug (SWD)
On-board SWD (JTAG) programmer circuitry (USB2 to BL654 module SWD interface)
smartBASIC runtime engine FW upgrade capability:
Via UART (using the FTDI USB1-UART)
Via SWD (USB2 to BL654 SWD) using on-board JTAG programmer circuitry on the BL654 Development Kit
smartBASIC application upgrade capability:
Via UART (using the FTDI USB-UART)
Via OTA (Over-the-Air)
