CBF054_037P
14
(Continued on the next page.)
FIG. 16
X 1
X 2
27
28
28
27
Note: Make sure that the
Locking Pins are closed
to secure the mainframe.
FIG. 17
32
Note: Open the Locking Pins.
Note: To complete this step, the billiards
side must be facing upwards. If not,
disengage all 4 Locking Pins (#32), swivel
the table and then re-engage the Locking
Pins.
FIG. 17A
FIG. 17B
To Next Page
