CLIMATE CONTROL
SIDE AIR DIFFUSERS
A fig. 29 - Adjustable and directable side air
diffusers:
❒ use device B to adjust the vent to the required
position;
❒ turn wheel C to adjust the air flow.
D - Fixed side air diffuser.
CENTRAL AIR DIFFUSERS
A fig. 30 - Adjustable and directable central air
diffusers:
❒ use device B to adjust the vent to the required
position;
❒ turn wheel C to adjust the air flow.
fig. 29
L0F0103
fig. 30
L0F0104
