WARNING
If you are travelling in an area with
limited opportunities for
vehicle
refueling and you wish to bring petrol with
you in a petrol can, you must do so in
compliance with current regulations and
using an approved can, appropriately
secured to the load securing attachments.
However, by doing so, you increase the risk
of fire in case of an accident with your
vehicle.
BONNET
OPENING
Proceed as follows:
❒ pull lever A fig. 63 in the direction indicated by
the arrow;
❒ move lever B fig. 64 to the left as shown in the
figure;
❒ lift the bonnet and, at the same time, release
the supporting rod C fig. 65 from its catch D,
then insert the end of the rod into housing E in
the bonnet (larger hole) and push to safety
position (smaller hole), as shown in the figure.
fig. 63
L0F0096
74
