58
1. Install the upper running wheels in the
two panes.
Note: The upper castors are adjustable; if,
after fitting the shower enclosure, the doors
do not slide smoothly, they can be adjusted
using the lower screw on the upper bearing.
2. Install the lower running wheels (with qui-
ck release button).
2
1. Insert the fixed wall between the wall and
the aluminium profile of the sliding wall.
2. Finish by fixing the wall profile to the wall
using screws on previously inserted wall
plugs .
NOTE: nothing goes under the fixed slab, it
must be placed and siliconed from the outsi-
de.
1
1
2
