Lanier R/C CAP 232 - Page 16

Lanier R/C
16
(2) #6 – 32 x 1” Soc Hd. Cap screw (to hold wings on
spar)
TailTail
(10) Robart Super Hinge
(2) #6 x 2-1/2” pan hd. Mach. Screw control horn)
(elev.)
(1) #6 x 3” threaded rod full thread control horn)
(rudder)
(6) #6 flat washer
(4) #6 lock washer
(4) #6 hex nut
(4) #6 horn bracket
(2) #4-40 x 4” threaded rod (elev.) (2) #4-40 x 10”
threaded rod (rudder)
(8) #4-40 clevis
(8) #4 hex nut
(1) Sullivan tail Wheel 10 –22 lbs - 1-1/4 “ wheel -
(2) 3/32” wheel collar
(4) #4 rd. head sheet metal screw
CANOPYCANOPY
(2) #6 X ¾” Soc. Hd. Bolt
(2) #6 blind nut
(2) #6 flat washer
(2) #6 lock washer
COWLCOWL
(4) #6 x ¾” soc hd. Bolt
(4) #6 blind nut
LANDING GEARLANDING GEAR
(2) ¼-20 x 1” soc. hd. cap screw
(5) ¼” flat washer
(1) ¼” split lock washer
((2) ¼-20 lock nut
(1) ¼-20 T-nut
(4) 3/16 wheel collar
(2) 3-1/2” wheel
(2) 3/16 X 2” wheel axle
MISCMISC
(1) 24 oz fuel tank gas only (glow fuel stopper and tube
not supplied)
(1) fuel tank platform (laser cut part) ¼” lite-ply
(2) 14” plastic tie strap
(1) firewall 4-1/8” x 4-13/16” birch ply
(2) engine box bottom 5-5/16” x 6-1/2” lite ply (laser
cut part)
(1) servo mount (laser cut part)
(1) ½” balsa tri-stock x 30”
WHEEL PANTSWHEEL PANTS
(2) #6-32 x ½ Soc Hd. Bolt
(2) #6-32 blind nut
(2) #6 split lock washer
