FW-8894 User Manual
Thank you for choosing Lanner FW-8894. The FW-8894 is the 1U version of our already launched powerful
platform of FW-8896. It leverages many technological advancements as followed:
Dual Intel® Haswell-EP Xeon® E5-2600 v3 CPUs with C612 chipset. Driven by dual Intel® Xeon®
E5-2600 v3 CPUs with C612 chipset (codenamed “Grantley”), this new platform delivers excellent
efficiency and performance. The architecture of this next generation platform supports quad-channel
memory, up to 512GB of registered DDR4 RAM and 40 PCIe 3.0 lanes. Regarding the chipset, Intel®
C612 PCH (codenamed “Wellsburg”) with ultra peripheral connectivity supporting multiple PCIe lanes,
SATA ports, USB ports and IPMI/OPMA.
Intel® QPI® links up to 9.6 GT/s
FW-8896 is built with dual Intel Xeon CPUs and connected by the latest Intel QPI links up to 9.6 GT/s to
keep latency down to minimal even during heavy workloads.
Up to Eight Ethernet modules with 32 GbE ports:
Under 1U rackmount form factor, Lanner FW-8894 can fit in up to 4 Ethernet modules, with a total of
up to 32 GbE ports. The appliance also supports 1/10G RJ-45 or 1/10/40G fiber Ethernet. NIC modules
are available for further expansion (optional).
Support hot-swappable cooling fans with smart fan control
Cooling fans are essential especially in rackmount applications. The hot-swappable mechanism allows
easy replacement of worn-out fans to ensure constant and reliable operations.
Intel® Coleto Creek 8925 acceleration engine
The integration of Intel Coleto Creek 8925 delivers up to 25 Gbps throughput and provides an optimal
boost to handle repetitive and large-scale mathematical loads.
Intel® QuickAssist Technology
The Intel Grantley platform comes with Intel QuickAssist Technology, accelerating security packet and
compression processes.
Your package contains the following items:
FW-8894 Network Security Platform
2x power cords
1x RoHS-compliant D-Sub 9-pin to RJ-45 8-pin console cable (080W250918001)
1x Cat.5e cross-over Ethernet cable (080W2E0818005)
1x Cat.5e Ethernet cable in grey (080W2E0818006)
1x SATA 7-pin cable (080W000125000)
Optional:
RC-8894 1A PCIe riser card (RC-8896 1A, brackets, and screws) 2U slide kit
IPMI Card: IAC-AST2300
TPM Module: IAC-TPM01A / IAC-TPM01B
Note: If any component should be missing or damaged, please contact your dealer immediately
for assistance.
