8. Repeat the procedure for the bottom location, starting from the right side, but locate the vertical position by:
1. Laying the piercing nger against the load, pointed downward.
2. The bottom of the 10” piercing nger should extend 3/4” below the bottom of the lm (including lm rope or Pallet Grip
cable). (See Photo - 10)
3. Where the piercing nger intersects with the top plate, mark the position with your nger. Insert the piercing nger at
that mark. (See Photo - 10)
4. When inserted, the tool position should look like Photo - 11.
9. After all of the readings have been taken, push and hold the button on the scale for approx. 5 seconds until the unit turns off.
As in any test, consistency is important. Repeat the sequence the same way every time and you will get accurate data points.
Photo - 10 Insert piercing nger on the bottom
measurement
Photo - 11 Make sure to capture the cable with the tool
Common Errors
Avoid these common errors.
Insert
piercing
nger here
Tool not vertical Scale not level
Avoid lm bunching
