Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 203
<text>
a single character. Note that quotes must enclose the value if it contains spaces.
aes encrypt key <hexa-
decimal>
Sets the connect tunnel AES encrypt key with up to 16 bytes. Each byte is represented by
two adjacent hex digits. Bytes may run together or be separated by optional punctuation:
123ABC "12 3A BC" 12,3A,BC 12.3a.bc 12:3a:bc Note that quotes must enclose the value
if it contains spaces.
aes encrypt key text
<text>
Sets the connect tunnel AES encrypt key with up to 16 bytes. Each byte is represented by
a single character. Note that quotes must enclose the value if it contains spaces.
auto show statistics
show connection statistics
clrscrn
Clears the screen.
credentials <text>
Selects the RSA/DSA certificates by name for the SSL client.
default protocol
Restores the default connect mode tunneling protocol as 'TCP'.
default secure protocols
Restores the default secure protocol selections.
default tcp keep alive
Defaults the TCP keep alive idle time.
default tcp keep alive
interval
Restores the default 45 second connect mode TCP keep alive timeout.
default tcp keep alive
probes
Defaults the TCP keep alive probes.
exit
Exits to the next higher level.
initial send binary <bina-
ry>
Sets the host connect tunnel Initial Send text allowing for binary characters. <binary> =
string in binary format that will be sent out the network upon connection. Within [] use bina-
ry decimal up to 255 or hex up to 0xFF.
initial send set <text>
Sets the host connect tunnel Initial Send text. <text> = ascii string that will be sent out the
network upon connection.
no address
Removes the remote host address used to establish tunneling connections.
no aes decrypt key
Removes the connect tunnel AES decrypt key.
no aes encrypt key
Removes the connect tunnel AES encrypt key.
no credentials
Clears the RSA/DSA certificate selection for the SSL client.
no initial send
Removes the host connect tunnel Initial Send string.
no port
Removes the remote port used to establish tunnel connections.
no ssh username
Removes the SSH user name.
no tcp user timeout
Restores the default.
port <number>
Sets the remote port to use for connect mode tunneling. <number> = number of the port to
use.
protocol ssh
Uses SSH protocol for connect mode tunneling.
protocol ssl
Uses SSL protocol for connect mode tunneling.
protocol tcp
Uses TCP protocol for connect mode tunneling.
protocol tcp aes
Uses TCP protocol with AES encryption for connect mode tunneling.
protocol telnet
Uses Telnet protocol (with IAC) for connect mode tunneling.
protocol udp
Uses UDP protocol for connect mode tunneling.
protocol udp aes
Uses UDP protocol with AES encryption for connect mode tunneling.
secure protocols ssl3
disable
Disables the protocol.
secure protocols ssl3
enable
Enables the protocol.
secure protocols tls1.0
disable
Disables the protocol.
secure protocols tls1.0
enable
Enables the protocol.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
