Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 313
reassert
Asserts line status with current configured values.
show
Displays the current status.
show command mode
Shows the command mode settings for the current line.
show history
Displays the last 20 commands entered during the current CLI session.
show line
Displays the current configuration.
show statistics
Shows the line statistics.
state disable
Disables the line so data cannot be sent/received.
state enable
Enables the line so data can be sent/received.
stop bits 1
Uses one stop bit after data on the line.
stop bits 2
Uses two stop bits after data on the line.
terminal <line>
Enters the configure-terminal level. <line> = number of the terminal line (serial port) to be
configured.
terminal network
Enters the configure-terminal level for the network.
threshold <bytes>
Sets the threshold in bytes. After this many bytes are received, they are forwarded without
delay.
tunnel <line>
Enters the tunnel level. <line> = number of the tunnel line (serial port) to be configured.
usb <line>
Enters the usb level. <line> = number of the line (usb port) to be configured.
write
Stores the current configuration in permanent memory.
xoff char <control>
Sets the xoff character for use with software flow control on this line. The character may be
input as text, control, decimal, or hex. A control character has the form <control>C. A dec-
imal value character has the form \99. A hex value character has the form 0xFF.
xon char <control>
Sets the xon character for use with software flow control on this line. The character may be
input as text, control, decimal, or hex. A control character has the form <control>C. A dec-
imal value character has the form \99. A hex value character has the form 0xFF.
line 2 (config-mach10-line:2) level commands
clrscrn
Clears the screen.
command delimiter
<text>
Sets the command delimiter.
content check interval
<hours>
Sets the firmware and configuration check interval.
default command delim-
iter
Restores the command delimiter.
default content check
interval
Restores the default firmware and configuration check interval.
default local port
Clears the local port for Mach10 client.
default status update
interval
Restores the default status update interval.
exit
Exits to the config-mach10 level.
line <number>
Change to line configuration level.
local port <number>
Sets the local port for Mach10 client. When configured, a total of 16 consecutive ports will
be reserved.
no project tag
Restores the default Project Tag.
project tag <text>
Sets the Project Tag.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
state disable
Disables command processing on line.
state enable
Enables command processing on line.
status update interval
Sets the status update interval.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
