Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 330
no friendly name
Remove the friendly name.
no ingress ip address
Clears the original WAN destination IP address for port forwarding rule.
no ip address
Clears the LAN destination IP address for port forwarding rule.
no port or range
Clears the WAN port or range for port forwarding rule.
no target port
Clears the LAN destination port for port forwarding rule.
port forwarding rule
<number>
Change to config gateway port forwarding level.
port or range <text>
Sets the WAN port or range for port forwarding rule. <text> = port or range.
protocol both
Sets the protocol to Both (TCP and UDP).
protocol tcp
Sets the protocol to TCP.
protocol udp
Sets the protocol to UDP.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
state disable
Disables the port forwarding rule.
state enable
Enables the port forwarding rule.
target port <text>
Sets the LAN destination port for port forwarding rule. <text> = port.
write
Stores the current configuration in permanent memory.
port forwarding rule 5 (config-portforwarding:5) level commands
clrscrn
Clears the screen.
default protocol
Restores the default value of the protocol (Both).
exit
Exits to the config-gateway level.
friendly name <text>
Set the friendly name for port forwarding rule <text> = friendly name
ingress ip address <text>
Sets the original WAN destination IP address for port forwarding rule.
ip address <text>
Sets the LAN destination IP address for port forwarding rule.
no friendly name
Remove the friendly name.
no ingress ip address
Clears the original WAN destination IP address for port forwarding rule.
no ip address
Clears the LAN destination IP address for port forwarding rule.
no port or range
Clears the WAN port or range for port forwarding rule.
no target port
Clears the LAN destination port for port forwarding rule.
port forwarding rule
<number>
Change to config gateway port forwarding level.
port or range <text>
Sets the WAN port or range for port forwarding rule. <text> = port or range.
protocol both
Sets the protocol to Both (TCP and UDP).
protocol tcp
Sets the protocol to TCP.
protocol udp
Sets the protocol to UDP.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
state disable
Disables the port forwarding rule.
state enable
Enables the port forwarding rule.
target port <text>
Sets the LAN destination port for port forwarding rule. <text> = port.
write
Stores the current configuration in permanent memory.
port forwarding rule 6 (config-portforwarding:6) level commands
clrscrn
Clears the screen.
default protocol
Restores the default value of the protocol (Both).
exit
Exits to the config-gateway level.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
