Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 363
ping interval <minutes>
Sets the ping interval.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
usb 1 (usb-line:1) level commands
auto show statistics
Continuously displays line statistics.
baud rate <bits per sec-
ond>
Sets the line speed. <bits per second> = the speed. Standard speeds include 1200, 2400,
4800, 9600, 19200, and so on.
bluetooth serial <line>
Enters the bluetooth serial level. <line> = number of the line (bluetooth serial port) to be
configured.
clear line counters
Sets the serial counters to zero.
clrscrn
Clears the screen.
command mode always
Sets the current line to always be in command mode.
command mode echo
serial string disable
Disables user-defined serial boot string to be echoed in the CLI.
command mode echo
serial string enable
Enables user-defined serial boot string to be echoed in the CLI.
command mode serial
string
Enables user to enter a custom string at boot time to enter command mode.
command mode serial
string <string>
Sets a string that can be entered at boot time to enter command mode. <string> = text with
possible binary characters. Within [] use binary decimal up to 255 or hex up to 0xFF. Within
{} specify decimal milliseconds time delay.
command mode signon
message <string>
Sets a sign-on message that is sent from the serial port when the device boots and when
the line is in command mode. <string> = text with possible binary characters. Within [] use
binary decimal up to 255 or hex up to 0xFF.
command mode wait
time <milliseconds>
Sets boot-up wait time for command mode serial string. <milliseconds> = wait time.
data bits 7
Uses seven bits for data on the line.
data bits 8
Uses eight bits for data on the line.
default baud rate
Restores the default speed of 115200 bits per second.
default data bits
Restores the default of eight data bits.
default flow control
Restores the default of hardware (RTS/CTS) flow control.
default line mode
Restores the default usb line mode.
default parity
Restores the default of no parity.
default stop bits
Restores the default of one stop bit.
default threshold
Restores the factory default threshold.
default xoff char
Restores the default xoff character on this line.
default xon char
Restores the default xon character on this line.
exit
Exits to the enable level
flow control hardware
Uses hardware (RTS/CTS) flow control on the line.
flow control none
Does not provide flow control on the line.
flow control software
Uses software (xon/xoff characters) flow control on the line.
gap timer <milliseconds>
Sets the gap timer in milliseconds. If some data has been received, it will be forwarded
after this time since the last character.
interface usb-cdc-acm
Sets the usb line interface to USB-CDC-ACM.
kill session
Kills command mode session on the Line
line <line>
Enters the line level. <line> = number of the line (serial port) to be configured.
line mode ethernet de-
Sets the usb line to ethernet device mode.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
