5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 91
default mqtt host
Restores the Hostname or IP address of MQTT server.
default mqtt local port
Clears the local port for Mach10 MQTT client.
default mqtt port
Restores the Port of MQTT server.
default port
Restores the Port of Mach 10.
default proxy port
Restores the Port of proxy server.
default proxy type
Restores the default Proxy server type (SOCKS5).
exit
Exits to the next higher level.
host <text>
Sets the Hostname or IP address of Mach 10.
local port <number>
Sets the local port for Mach10 client. When configured, a total of 16 consecutive ports will
be reserved.
mqtt host <text>
Sets the Hostname or IP address of MQTT server.
mqtt local port <number>
Sets the local port for Mach10 MQTT client. When configured, a total of 32 consecutive
ports will be reserved.
mqtt port <number>
Sets the Port of MQTT server.
mqtt security disable
Disables SSL for MQTT.
mqtt security enable
Enables SSL for MQTT.
mqtt state disable
Disables MQTT.
mqtt state enable
Enables MQTT.
no proxy host
Restores the Hostname or IP address of the proxy server.
no proxy password
Restores the password for proxy server.
no proxy username
Clears the user name for the proxy server.
port <number>
Sets the Port of Mach 10.
proxy host <text>
Sets the Hostname or IP address of the proxy server.
proxy password <text>
Sets the password the proxy server.
proxy port <number>
Sets the Port of the proxy server.
proxy type socks5
Sets the Proxy server type to SOCKS5
proxy username <text>
Sets the user name for the proxy server.
secure port disable
Disables HTTPS for Mach10 client.
secure port enable
Enables HTTPS for Mach10 client.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
use proxy disable
Disables use of proxy server for this connection.
use proxy enable
Enables use of proxy server for this connection.
validate certificates disa-
ble
Disables certificate validation for Mach10 client.
validate certificates ena-
ble
Enables certificate validation for Mach10 client.
write
Stores the current configuration in permanent memory.
connection 2 (config-action-http_post-connection:wlan0 link state change:2) level commands
clrscrn
Clears the screen.
default local port
Uses a random port number as the local port.
default port
Sets default Port number.
default protocol
Sets default HTTP Protocol.
exit
Exits to the next higher level.
host <text>
Sets HTTP server IP address or hostname to be connected to.
local port <number>
Sets a specific port for use as the local port. <number> = the number of the port to use.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
